Hi All,

some time ago I removed this undertray cover while working on the front end...since then, I've forgotten how it is fitted! Does anyone know its precise location? Some photos would be useful, thanks



[Dr HMS Derv Destroyer]

Should be riv nuts on the subframe for where it fits



[stourlos]

On which side? Where exactly? Near which part?



[loggyboy]

Its the one that goes vertically on the passenger side front arch, near the front gearbox mount.

not my image, but googles first clear showing of it

PS, your image needs to finish in .jpg, not sure how you do then when uploading to the sites image store - but I found your picture by looking for latest uploads.
